Dimensions
- Width
- 258 mm
- Height
- 362 mm
- Depth
- 218 mm
Specifications
- NominalV
- 12
- Idle consumption w
- 20
- Efficiency percent
- 94
- Continuous power w
- 2400
- Surge power w
- 6000
- Output voltage v
- 230
- Waveform
- pure_sine
Terminals (6)
| Terminal | Type | Connection |
|---|---|---|
| + BATT - | + positive | Stud / bolt · M8 |
| − negative | − negative | Stud / bolt · M8 |
| AC in L | AC | Screw / cage clamp |
| AC in N | AC | Screw / cage clamp |
| AC out L | AC | Screw / cage clamp |
| AC out N | AC | Screw / cage clamp |
Connection = how a cable attaches (ring lug, MC4, stud, bare wire…) and the conductor size it accepts. Used to build the connector list in your bill of materials.
