Dimensions
- Width
- 186 mm
- Height
- 130 mm
- Depth
- 60 mm
Specifications
- Max input voltage v
- 100
- Max output current a
- 50
- Efficiency percent
- 98
- Charger technology
- MPPT
Terminals (4)
| Terminal | Type | Connection |
|---|---|---|
| BAT+ | + positive | Screw / cage clamp |
| BAT− | − negative | Screw / cage clamp |
| PV− | − negative | Screw / cage clamp |
| PV+ | + positive | Screw / cage clamp |
Connection = how a cable attaches (ring lug, MC4, stud, bare wire…) and the conductor size it accepts. Used to build the connector list in your bill of materials.
