Dimensions
- Width
- 92 mm
- Height
- 92 mm
- Depth
- 70 mm
Specifications
- Amperage rating a
- 300
- Voltage rating v
- 48
Terminals (2)
| Terminal | Type | Connection |
|---|---|---|
| Input | + positive | Stud / bolt · M10 · ≤ 120 mm² |
| B | + positive | Stud / bolt · M10 · ≤ 120 mm² |
Connection = how a cable attaches (ring lug, MC4, stud, bare wire…) and the conductor size it accepts. Used to build the connector list in your bill of materials.
