Dimensions
- Width
- 103 mm
- Height
- 38 mm
- Depth
- 42 mm
Specifications
- Amperage rating a
- 300
- Interrupt rating a
- 2000
- Voltage rating v
- 32
- Fuse type
- MEGA
Terminals (2)
| Terminal | Type | Connection |
|---|---|---|
| Input Stud | + positive | Ring terminal / lug · M8 |
| Output Stud | + positive· fuse 100 | Ring terminal / lug · M8 |
Connection = how a cable attaches (ring lug, MC4, stud, bare wire…) and the conductor size it accepts. Used to build the connector list in your bill of materials.
